The figures below are the reference values for the standard build of this model. The actual configuration is adjusted to the oil, the throughput and the power supply on site; the technical agreement signed by both sides is what counts.
LX-100 centrifugal oil purifier
A high-speed rotor separates contaminants by centrifugal force, for uninterrupted oil clarification on continuous production lines.
01Applications
For clarifying oil on continuous production lines, where oil volumes are large, uninterrupted operation is needed and consumable cost should be kept down.
Gear oil, hydraulic oil, lubricating oil and waste oil with a high contaminant load.
Standard: high carbon steel; custom-built: 304 stainless steel
The high-speed rotor spins the oil, and solid contaminants are thrown against the outer wall of the separation chamber by centrifugal force and discharged together, while the oil flows out from the centre. Separation efficiency is higher than with static filtration.
02Overview
A high-speed rotor separates contaminants by centrifugal force, for uninterrupted oil clarification on continuous production lines.
Each machine is designed and built to the company standard and goes through a no-load and a full-load run test before it leaves the works. The test record and the certificate of conformity travel with the machine. Yanneng can work out the right configuration and the treatment line from the oil analysis report and the site conditions you provide.
03Main features
04Technical data
| Flow rate | 2400 L/h |
|---|---|
| Separation method | High-speed centrifugal separation |
| Filtration accuracy | ≤5 μm |
| Power supply | Three-phase 380V / 50Hz |
| Equipment weight | approx. 560 kg |
The figures above are the reference values for the standard build. The actual configuration can be adjusted to the oil, the throughput and the power supply on site; the technical agreement signed by both sides is what counts.
05Optional items
- Automatic sludge discharge interface available as an option
- Interlocked speed monitoring and over-pressure protection available as an option
- Can be used with oil heating to maintain a suitable viscosity
06Common questions
Centrifugal separation suits continuous operation, high throughput and low consumable cost. Plate and frame filtration suits oil of high viscosity, oil with a high contaminant load, and duties where the filter cake has to be recovered.
07Related models
Need a quotation, a delivery date or a custom build?
Tell us the conditions this machine has to work in - the oil type, the throughput, the power supply and where it will be installed - and we will come back within one working day with a configuration recommendation and a quotation.
