LY-50 plate and frame filter press
10 sets of 200×200 plate and frame assemblies, a general-purpose configuration already proven by many customers, with short delivery time and interchangeable parts.
01Applications
For coarse filtration and deep filtration of high-viscosity oils, waste oils and oils with a high solids load. Suitable for metallurgy, mining, steel, power generation, shipyards and other applications where solid contaminants have to be separated out completely.
High-viscosity oils such as gear oil, hydraulic oil and heat transfer oil, and waste oils with a high solids load.
Standard: high carbon steel; custom-made: 304 stainless steel
10 sets of 200×200 plate and frame assemblies form the filter chambers. The oil passes through the filter paper and cloth between the clamped frames, and solid contaminants are retained as filter cake. During filtration a single frame can be withdrawn for cake removal while the remaining chambers keep working.
02Overview
10 sets of 200×200 plate and frame assemblies, a general-purpose configuration already proven by many customers, with short delivery time and interchangeable parts.
Each machine is designed and built to the company standard and goes through a no-load and a full-load run test before it leaves the works. The test record and the certificate of conformity travel with the machine. Yanneng can work out the right configuration and the treatment line from the oil analysis report and the site conditions you provide.
03Main features
04Technical data
| Flow rate | 1200 L/h |
|---|---|
| Number of plate and frame sets | 10 sets |
| Plate and frame size | 200 × 200 mm |
| Filtration accuracy | ≤5 ~ 20 μm |
| Motor power | 4 kW |
| Oil pump | kcb33.3 |
| Power supply | three-phase 380V / 50Hz |
| Weight | approx. 520 kg |
The figures above are the reference values for the standard build. The actual configuration can be adjusted to the oil, the throughput and the power supply on site; the technical agreement signed by both sides is what counts.
05Standard configuration
| Item | Quantity | Brand |
|---|---|---|
| Plate and frame sets | 10 sets | 200 × 200 |
| Motor | 1 set | 4-1.5-b3 |
| Oil pump | 1 set | kcb33.3 |
06Optional items
- Coarse and fine filtration stages can be combined
- Manual or hydraulic clamping available as an option
- Matching oil transfer piping and an automatic cake discharge unit can be built to suit the customer tank capacity
